MPS Series Multi-process IGBT Inverter Welders

Product Introduction

Function: FCAW-SS, SMAW (cellulose stick), SMAW (low hydrogen stick), GTAW

Product characteristics

  • 01National level energy saving products (Energy efficiency rating :Ⅱ);
  • 02Independent cooling wind path, dust-proof, sand-proof, water-proof and vibration-proof, good environmental adaptability;
  • 03Digital preset and display of welding current and voltage;
  • 04IGBT inverter power source, high-efficiency and energy-saving;
  • 05Good electromagnetic compatibility;
  • 06MPS-500(D) has the function of remote data acquisition and data management to ensure welding quality.

Main Technical Parameters

Model MPS-500
Product ID 4062000000
Input Power Supply 3 phase 380V±25% 50/60Hz
Rated Input Power 25kVA
Rated Input Current 38A
Rated Output Current/Voltage 500A/40V
Rated Duty Cycle 60%
Max. Open-Circuit Voltage CV 79V
CC 74V
Output Voltage Range(CV) 17~39V(60~500A)
Output Current Range(CC) 50~490A
Cooling  Air cooling
Ambient Temperature -40~55℃
Altitude 4000m
IP Rating IP23
Accessories XG-90LNWire feeder、MOG-350Self-shielded welding gun XG-90LN wire feeder, MOG-350 self-shielding torch
Weight 49kg
Dimensions(W×L×H) 350mm×600mm×460mm
